2020 ATV Polaris A20SGE95AK SCRAMBLER XP 1000 55" (2020) (R05) (A20SGE95AK) SUSPENSION, FRONT A-ARMS - A20SGE95AK (C101478) OEM Parts | Assembly Diagram OEM Parts Finder and Diagram (Microfiche) Inspector

Polaris Choose parts...

Use scroll wheel, or pinch and drag to and .

1
Item # 1650363
Polaris / Indian Weld-UCA Front 55" Left Red - 1025579-293
Out of Stock
$219.99
          Recommended Quantity: 1

          This part has 1 location on the diagram. It is the recommended quantity, but not a requirement.

          Stock: TBD
          2
          Item # 1650364
          Polaris / Indian Weld-UCA Front 55" Right Red - 1025580-293
          Leaves Warehouse: 3 to 4 days
          $219.99
                  Recommended Quantity: 1

                  This part has 1 location on the diagram. It is the recommended quantity, but not a requirement.

                  Stock: TBD
                  3
                  Item # 1648339
                  Polaris / Indian Weld Lower Control Arm Front 55 Left Red - 1023399-293
                  Leaves Warehouse: 3 to 4 days
                  $269.99
                          Recommended Quantity: 1

                          This part has 1 location on the diagram. It is the recommended quantity, but not a requirement.

                          Stock: TBD
                          4
                          Item # 1648345
                          Polaris / Indian Weld Lower Control Arm Front 55 Right Red - 1023400-293
                          Leaves Warehouse: 3 to 4 days
                          $269.99
                                  Recommended Quantity: 1

                                  This part has 1 location on the diagram. It is the recommended quantity, but not a requirement.

                                  Stock: TBD
