2016 KTM 250 XCFW Engine - 2016 Cylinder OEM Parts | Assembly Diagram OEM Parts Finder and Diagram (Microfiche) Inspector

KTM Choose parts...

Use scroll wheel, or pinch and drag to and .

1
Item # 1047605
KTM / GasGas / Husqvarna Cylinder and Piston - 77730038100
Leaves Warehouse: 2 to 3 days
$958.79
          Recommended Quantity: 1

          This part has 1 location on the diagram. It is the recommended quantity, but not a requirement.

          Stock: TBD
          2
          Item # 1080286
          KTM / GasGas / Husqvarna Dowl Sleeve 10.2x12.5x10 - 58530014100
          Leaves Warehouse: 2 to 3 days
          $5.27
                  Recommended Quantity: 2

                  This part has 2 locations on the diagram. It is the recommended quantity, but not a requirement.

                  Stock: TBD
                  3
                  Item # 1046688
                  KTM / Husqvarna Cylinder Base Gasket - 77230035000
                  Leaves Warehouse: 2 to 3 days
                  $18.83
                          Recommended Quantity: 1

                          This part has 1 location on the diagram. It is the recommended quantity, but not a requirement.

                          Stock: TBD
