2015 KTM 50 SX MINI Chassis - 2015 Monoshock OEM Parts | Assembly Diagram OEM Parts Finder and Diagram (Microfiche) Inspector

KTM Choose parts...

Use scroll wheel, or pinch and drag to and .

1
Item # 1033406
KTM Monoshock 50 SX/TC Mini 20 - 03189T0101
Out of Stock
$1,096.10
          Recommended Quantity: 1

          This part has 1 location on the diagram. It is the recommended quantity, but not a requirement.

          Stock: TBD
          2
          Item # 1033325
          KTM / GasGas / Husqvarna Washer DIN 125 A 10.5 - 0125100003
          Leaves Warehouse: Same Day
          $2.89
                  Recommended Quantity: 4

                  This part has 4 locations on the diagram. It is the recommended quantity, but not a requirement.

                  Stock: TBD
                  3
                  Item # 1034307
                  KTM / GasGas / Husqvarna Self Lock.Nut DIN0982-M10 High - 0982100003
                  Leaves Warehouse: 2 to 3 days
                  $2.89
                          Recommended Quantity: 2

                          This part has 2 locations on the diagram. It is the recommended quantity, but not a requirement.

                          Stock: TBD
                          4
                          Item # 1034259
                          KTM / Husqvarna HH Screw DIN0931-M10X45 - 0931100453
                          Leaves Warehouse: 2 to 3 days
                          $4.34
                                  Recommended Quantity: 2

                                  This part has 2 locations on the diagram. It is the recommended quantity, but not a requirement.

                                  Stock: TBD
