1986 Honda Powersports CH250AC (86) ELITE 250, JPN, VIN# JH2MF011-GK100001 TO JH2MF011-GK101844 FRONT FORK 85-87 OEM Parts | Assembly Diagram OEM Parts Finder and Diagram (Microfiche) Inspector

OEM Parts
Honda Powersports
MOTOR SCOOTER
1986
CH250AC (86) ELITE 250, JPN, VIN# JH2MF011-GK100001 TO JH2MF011-GK101844
FRONT FORK 85-87

1 2 3 4 4 6 7 8 9 10 11 12 13 14 15 16 16 17 18 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 37 38 39 40 41

Use scroll wheel, or pinch and drag to and .

MPN/SKU: 50301-KN7-670

RACE, STEERING BALL (UPPER)

Unavailable

$8.89

Recommended Quantity: 1

This part has 1 location on the diagram. It is the recommended quantity, but not a requirement.

Stock: TBD

Item # 1261344

Honda Race Steering Ball (Lower) - 50302-268-010

Leaves Warehouse: 3 to 4 days

$28.30

Recommended Quantity: 1

This part has 1 location on the diagram. It is the recommended quantity, but not a requirement.

Stock: TBD

MPN/SKU: 50306-147-003

NUT, STEERING STEM LOCK (MITSUBOSHI)

Unavailable

$7.75

Recommended Quantity: 1

This part has 1 location on the diagram. It is the recommended quantity, but not a requirement.

Stock: TBD

MPN/SKU: 51103-KM1-010

COVER, R. PIVOT ARM

Unavailable

$11.38

Recommended Quantity: 1

This part has 1 location on the diagram. It is the recommended quantity, but not a requirement.

Stock: TBD

MPN/SKU: 51103-KM1-010

COVER, R. PIVOT ARM

Unavailable

$11.38

Recommended Quantity: 1

This part has 1 location on the diagram. It is the recommended quantity, but not a requirement.

Stock: TBD

MPN/SKU: 51104-KM1-010

COVER, L. PIVOT ARM

Unavailable

$11.38

Recommended Quantity: 1

This part has 1 location on the diagram. It is the recommended quantity, but not a requirement.

Stock: TBD

MPN/SKU: 51104-KM1-010

COVER, L. PIVOT ARM

Unavailable

$11.38

Recommended Quantity: 1

This part has 1 location on the diagram. It is the recommended quantity, but not a requirement.

Stock: TBD

MPN/SKU: 51105-KM1-670ZA

FORK, FR. *NH1* (BLACK)

Unavailable

$169.32

Recommended Quantity: 1

This part has 1 location on the diagram. It is the recommended quantity, but not a requirement.

Stock: TBD

MPN/SKU: 51152-KM1-000

LABEL 2, PIVOT ARM COVER

Unavailable

$1.00

Recommended Quantity: 2

This part has 2 locations on the diagram. It is the recommended quantity, but not a requirement.

Stock: TBD

MPN/SKU: 51313-KM1-000

COLLAR A, PIVOT ARM

Unavailable

$3.91

Recommended Quantity: 4

This part has 4 locations on the diagram. It is the recommended quantity, but not a requirement.

Stock: TBD

MPN/SKU: 51314-KM1-000

COLLAR B, PIVOT ARM

Unavailable

$3.70

Recommended Quantity: 2

This part has 2 locations on the diagram. It is the recommended quantity, but not a requirement.

Stock: TBD

MPN/SKU: 51320-KM1-306

ARM SUB, R. PIVOT (NOT AVAILABLE)

Unavailable

$38.33

Recommended Quantity: 1

This part has 1 location on the diagram. It is the recommended quantity, but not a requirement.

Stock: TBD

MPN/SKU: 51334-041-000

COLLAR, FR. FORK DISTANCE (LOWER)

Unavailable

$4.42

Recommended Quantity: 2

This part has 2 locations on the diagram. It is the recommended quantity, but not a requirement.

Stock: TBD

MPN/SKU: 51335-001-000

DUST SEAL, FR. FORK (LOWER)

Unavailable

$2.27

Recommended Quantity: 4

This part has 4 locations on the diagram. It is the recommended quantity, but not a requirement.

Stock: TBD

MPN/SKU: 51336-001-000

CAP, FR. FORK DUST SEAL (LOWER)

Unavailable

$2.36

Recommended Quantity: 4

This part has 4 locations on the diagram. It is the recommended quantity, but not a requirement.

Stock: TBD

MPN/SKU: 51400-KM1-673ZA

FORK ASSY., FR. *NH1* (BLACK) (NOT AVAILABLE)

Unavailable

$76.37

Recommended Quantity: 2

This part has 2 locations on the diagram. It is the recommended quantity, but not a requirement.

Stock: TBD

MPN/SKU: 51401-KM1-671

SPRING, FR. FORK (NOT AVAILABLE)

Unavailable

$14.85

Recommended Quantity: 2

This part has 2 locations on the diagram. It is the recommended quantity, but not a requirement.

Stock: TBD

MPN/SKU: 51410-KM1-672

DAMPER, FR. (NOT AVAILABLE)

Unavailable

$38.33

Recommended Quantity: 2

This part has 2 locations on the diagram. It is the recommended quantity, but not a requirement.

Stock: TBD

MPN/SKU: 51410-KM1-672

DAMPER, FR. (NOT AVAILABLE)

Unavailable

$38.33

Recommended Quantity: 2

This part has 2 locations on the diagram. It is the recommended quantity, but not a requirement.

Stock: TBD

MPN/SKU: 51412-KM1-003

COLLAR, FR. FORK (NOT AVAILABLE)

Unavailable

$3.38

Recommended Quantity: 2

This part has 2 locations on the diagram. It is the recommended quantity, but not a requirement.

Stock: TBD

MPN/SKU: 51414-KM1-013

METAL (LOWER)

Unavailable

$16.78

Recommended Quantity: 2

This part has 2 locations on the diagram. It is the recommended quantity, but not a requirement.

Stock: TBD

MPN/SKU: 51414-KM1-013

METAL (LOWER)

Unavailable

$16.78

Recommended Quantity: 2

This part has 2 locations on the diagram. It is the recommended quantity, but not a requirement.

Stock: TBD

MPN/SKU: 51420-KM1-306

ARM SUB, L. PIVOT (NOT AVAILABLE)

Unavailable

$37.49

Recommended Quantity: 1

This part has 1 location on the diagram. It is the recommended quantity, but not a requirement.

Stock: TBD

MPN/SKU: 51421-KM1-671ZA

CASE (LOWER) *NH1* (BLACK)

Unavailable

$9.34

Recommended Quantity: 2

This part has 2 locations on the diagram. It is the recommended quantity, but not a requirement.

Stock: TBD

MPN/SKU: 52460-GB4-721ZR

CASE, RR. SHOCK ABSORBER (UPPER) *NH1* (BLACK)

Unavailable

$32.05

Recommended Quantity: 2

This part has 2 locations on the diagram. It is the recommended quantity, but not a requirement.

Stock: TBD

MPN/SKU: 52517-KJ9-003

RUBBER, STOPPER

Unavailable

$3.43

Recommended Quantity: 2

This part has 2 locations on the diagram. It is the recommended quantity, but not a requirement.

Stock: TBD

MPN/SKU: 52476-001-020

BUSH, RR. SHOCK ABSORBER RUBBER

Unavailable

$5.82

Recommended Quantity: 2

This part has 2 locations on the diagram. It is the recommended quantity, but not a requirement.

Stock: TBD

MPN/SKU: 52481-173-000

NUT, LOCK (8MM) (NOT AVAILABLE)

Unavailable

$3.52

Recommended Quantity: 2

This part has 2 locations on the diagram. It is the recommended quantity, but not a requirement.

Stock: TBD

MPN/SKU: 52486-001-000

COLLAR, SWINGARM RUBBER BUSH

Unavailable

$5.75

Recommended Quantity: 2

This part has 2 locations on the diagram. It is the recommended quantity, but not a requirement.

Stock: TBD

MPN/SKU: 53211-KN7-670

RACE, STEERING TOP CONE

Unavailable

$10.29

Recommended Quantity: 1

This part has 1 location on the diagram. It is the recommended quantity, but not a requirement.

Stock: TBD

Item # 1273795

Honda Race Steering Cone (Lower) - 53212-250-010

Leaves Warehouse: 3 to 4 days

$24.01

Recommended Quantity: 1

This part has 1 location on the diagram. It is the recommended quantity, but not a requirement.

Stock: TBD

Item # 1273821

Honda Dust Seal - 53214-K0T-J00

Leaves Warehouse: 5 to 6 days

$3.89

Recommended Quantity: 1

This part has 1 location on the diagram. It is the recommended quantity, but not a requirement.

Stock: TBD

Item # 1273840

Honda Washer Steering Head Dust Seal - 53215-250-000

Out of Stock

$3.59

Recommended Quantity: 1

This part has 1 location on the diagram. It is the recommended quantity, but not a requirement.

Stock: TBD

MPN/SKU: 90149-041-010

BOLT, FR. FORK (LOWER)

Unavailable

$2.22

Recommended Quantity: 2

This part has 2 locations on the diagram. It is the recommended quantity, but not a requirement.

Stock: TBD

Item # 1363592

Honda Nut U (10MM) Nut Self-Lock (10MM) - 90304-GE8-003

Leaves Warehouse: 5 to 6 days

$4.92

Recommended Quantity: 2

This part has 2 locations on the diagram. It is the recommended quantity, but not a requirement.

Stock: TBD

Item # 1365182

Honda Bolt Flange (5X9) - 90508-GC8-000

Leaves Warehouse: 3 to 4 days

$5.87

Recommended Quantity: 2

This part has 2 locations on the diagram. It is the recommended quantity, but not a requirement.

Stock: TBD

MPN/SKU: 91257-KM1-003

DUST SEAL (16X26X4)

Unavailable

$5.02

Recommended Quantity: 4

This part has 4 locations on the diagram. It is the recommended quantity, but not a requirement.

Stock: TBD

Item # 1370953

Honda - 94002-08000-0S

Leaves Warehouse: 3 to 4 days

$2.33

Recommended Quantity: 2

This part has 2 locations on the diagram. It is the recommended quantity, but not a requirement.

Stock: TBD

Item # 1363592

Honda Nut U (10MM) Nut Self-Lock (10MM) - 90304-GE8-003

Leaves Warehouse: 5 to 6 days

$4.92

Recommended Quantity: 2

This part has 2 locations on the diagram. It is the recommended quantity, but not a requirement.

Stock: TBD

Item # 1371285

Honda Circlip (Inner) (26MM) - 94520-26000

Leaves Warehouse: 3 to 4 days

$2.67

Recommended Quantity: 2

This part has 2 locations on the diagram. It is the recommended quantity, but not a requirement.

Stock: TBD

Item # 1372099

Honda Bolt Flange (10X45) - 95801-10045-00

Leaves Warehouse: 5 to 6 days

$2.86

Recommended Quantity: 2

This part has 2 locations on the diagram. It is the recommended quantity, but not a requirement.

Stock: TBD

Item # 1372099

Honda Bolt Flange (10X45) - 95801-10045-00

Leaves Warehouse: 5 to 6 days

$2.86

Recommended Quantity: 2

This part has 2 locations on the diagram. It is the recommended quantity, but not a requirement.

Stock: TBD

Item # 1816976

Honda Bolt Flange (10X55) - 95801-10055-00

Out of Stock

$3.35

Recommended Quantity: 2

This part has 2 locations on the diagram. It is the recommended quantity, but not a requirement.

Stock: TBD

MPN/SKU: 96120-60000-10

BEARING, RADIAL BALL (6000)

Unavailable

$10.56

Recommended Quantity: 4

This part has 4 locations on the diagram. It is the recommended quantity, but not a requirement.

Stock: TBD

Item # 1372363

Honda Ball Steel (#5) (5/32) - 96211-05000

Leaves Warehouse: 3 to 4 days

$1.01

Recommended Quantity: 26

This part has 26 locations on the diagram. It is the recommended quantity, but not a requirement.

Stock: TBD

Item # 1372366

Honda Ball Steel (#8) (1/4) - 96211-08000

Leaves Warehouse: Same Day

$2.40

Recommended Quantity: 19

This part has 19 locations on the diagram. It is the recommended quantity, but not a requirement.

Stock: TBD

No results with applied page filter:

All Assemblies

For the current model: CH250AC (86) ELITE 250, JPN, VIN# JH2MF011-GK100001 TO JH2MF011-GK101844

See All
